CORNELL DUBILIER - 3186GH472M450MPC1 - Electrolytic Capacitor, Screw, 4700 µF, 450 V, ± 20%, Screw, 2000 hours @ 85°C
- Capacitance: 4700µF
- Voltage Rating: 450V
- Product Range: 3186 Series
- Lifetime @ Temperature: 2000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 76.2mm
- Lead Spacing: 31.8mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 142.9mm
- ESR: 0.031ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
