EPCOS - B57861S0103F045 - Thermistor, NTC, 10 kohm, B57861S Series, 3988 K, Through Hole, Wire Leaded
- Zero Power Resistance at 25°C: 10kohm
- Product Range: B57861S Series
- Thermistor Mounting: Through Hole
- Beta Value (K): 3988K
- Thermistor Case Style: -
- Thermistor Terminals: Wire Leaded
- Operating Temperature Min: -55°C
- Operating Temperature Max: 155°C
- Automotive Qualification Standard: AEC-Q200
- SVHC: No SVHC (27-Jun-2018)
- Beta Value Lower Limit Temperature: -40°C
- Body Diameter: 2.41mm
- External Length / Height: 50mm
- Lead Diameter: 0.25mm
- Lead Length: 43.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +155°C
- Resistance: 10kohm
- Resistance Tolerance: ± 1%
- Temperature Upper Limit Beta Value: 100°C
- Thermistor Tolerance: -1% to +1%
- Thermistor Type: NTC
