CAMDENBOSS - CSTBV23/2 - Standard Terminal Block, Wire to Board, CSTBV23, 2 Contacts, 5.08 mm, Terminal Block, PCB
- Product Range: CSTBV23 Series
- No. of Contacts: 2Contacts
- Pitch Spacing: 5.08mm
- Connector Type: Terminal Block, PCB
- Connector Mounting: PCB Mount
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 30AWG
- Contact Plating: Tin Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2019)
- Block Orientation: Through Hole Right Angle
- Colour: Grey
- Conductor Area CSA: 1.5mm²
- Current Rating: 16A
- External Length / Height: 10.16mm
- Height: 10.16mm
- Insulation Resistance: 5Mohm
- Material: UL94-V0 Flame Retardant PA66
- No. of Positions: 2Ways
- Operating Temperature Max: 125°C
- Operating Temperature Min: -20°C
- Rated Current: 10A
- Rated Voltage: 300V
- Screw Material: Zinc Plated Steel
- Temperature Max: +125°C
- Temperature Min: -20°C
- Voltage Rating VAC: 320V
- Wire Area Size Max: 1.5mm²
- Wire Connection Method: Clamp
- Wire Size (AWG): 30AWG to 16AWG
- Wire Size Range (AWG): 18-16
