MCHRS4FH-S-DC24V-C Relay, SPDT, 250VAC, 30Vdc, 10A multicomp Pro

MULTICOMP PROSKU:MCHRS4FH-S-DC24V-C Bestelcode:1695974

Prijs:
Actie prijs€4,69

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5423 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - MCHRS4FH-S-DC24V-C - General Purpose Relay, MCHRS4F Series, Power, SPDT, 24 VDC, 10 A

  • Contact Configuration: SPDT
  • Coil Voltage: 24VDC
  • Contact Current: 10A
  • Product Range: MCHRS4F Series
  • Relay Mounting: Through Hole
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Alloy
  • Coil Resistance: 1.6kohm
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 10A
  • Contact Current DC Max: 10A
  • Contact Current Max: 10A
  • Contact Voltage AC Max: 240V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 360mW
  • External Depth: 15.5mm
  • External Height: 15.8mm
  • External Length / Height: 15.8mm
  • External Width: 19mm
  • Nom Operating Power: 360mW
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Operating Time: 10ms
  • Relay Type: Power
  • Release Time: 5ms
