BERGQUIST - SPK6-0.006-00-104 - Thermal Pad, TO3P
- Insulator Body Material: Silicone Elastomer
- Thermal Conductivity: 1.1W/m.K
- Breakdown Voltage Vbr: 6kV
- Thickness: 0.152mm
- Volume Resistivity: 10ohm-m
- Thermal Impedance: 0.82°C/W
- Dielectric Strength: -
- Product Range: -
- SVHC: No SVHC (27-Jun-2018)
- Electrical Property Ins / Con: Insulative
- External Depth: 0.15mm
- Isolation Voltage: 6kV
- Material: Kapton MT Film
- Operating Temperature Max: 180°C
- Operating Temperature Min: -60°C
- Thermal Resistance: 0.3°C/W
- Type: Thermal Pad
