Description
WURTH ELEKTRONIK - 744031150 - Power Inductor (SMD), 15 µH, 620 mA, Shielded, 450 mA, WE-TPC
- Inductance: 15µH
- RMS Current (Irms): 620mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 450mA
- Product Range: WE-TPC Series
- Power Inductor Case: 3.8mm x 3.8mm x 1.65mm
- DC Resistance Max: 0.285ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Resonant Frequency: 30MHz
- Self Resonant Frequency Min: 30MHz
