Description
COILCRAFT - DO1608C-105MLC - Power Inductor (SMD), 1 mH, 150 mA, Unshielded, 100 mA, DO1608C
- Inductance: 1mH
- RMS Current (Irms): 150mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 100mA
- Product Range: DO1608C Series
- Power Inductor Case: 6.6mm x 4.45mm x 2.92mm
- DC Resistance Max: 13.8ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Self Resonant Frequency Min: 2MHz
