Description
VISHAY - MKP1848 615 454P4 - Power Film Capacitor, Metallized PP, Radial Box - 4 Pin, 15 µF, ± 5%, DC Link, Through Hole
- Capacitance: 15µF
- Voltage Rating: 500V
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 5%
- Product Range: MKP1848 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 37.5mm
- Operating Temperature Min: -
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 5%
- Capacitor Mounting: Through Hole
- ESR: 0.013ohm
- External Depth: 18.5mm
- External Length / Height: 35.5mm
- External Width: 37.5mm
- Height: 35.5mm
- Lead Diameter: 1mm
- Lead Length: 6mm
- No. of Pins: 4Pins
- Operating life Time: 100000h
- Voltage Rating V DC: 500V
