Description
VISHAY - RTO020F68000JTE3 - Through Hole Resistor, 6.8 kohm, RTO, 20 W, ± 5%, TO-220, 250 V
- Resistance: 6.8kohm
- Product Range: RTO Series
- Power Rating: 20W
- Resistance Tolerance: ± 5%
- Resistor Case Style: TO-220
- Voltage Rating: 250V
- Resistor Element Material: Thick Film
- Temperature Coefficient: ± 150ppm/°C
- Automotive Qualification Standard: -
- Element Limiting Voltage: 250V
- External Depth: 4.5mm
- External Length / Height: 28.7mm
- External Width: 10.1mm
- Full Power Rating Temperature: 25°C
- Lead Length: 13.7mm
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Overload Capability: 2 x Pr for 5 secs
- Power Rating with Heatsink: 20W
- Resistor Mounting: Through Hole
- Temperature Coeff. +: 150ppm/°C
- Temperature Coeff. -: 150ppm/°C
- Thermal Resistance: 6.5°C/W
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 250V
