T520C337M2R5ATE015 Cap, 330µF, 2.5V, 20%, 2312, SMD Kemet

KEMET - T520C337M2R5ATE015 - Tantalum Polymer Capacitor, KO-CAP®, 330 µF, ± 20%, 2.5 V, C, 0.015 ohm, 2312 [6032 Metric]

• Capacitance: 330µF
• Voltage Rating: 2.5V
• Product Range: T52X KO-CAP&reg
• Capacitance Tolerance: ± 20%
• Manufacturer Size Code: C
• ESR: 0.015ohm
• Operating Temperature Min: -55°C
• Operating Temperature Max: 105°C
• Automotive Qualification Standard: -
• SVHC: No SVHC (15-Jan-2018)
• Capacitance Tolerance ±: ± 20%
• Capacitor Case Style: 2312 [6032 Metric]
• Capacitor Mounting: SMD
• Capacitor Terminals: SMD
• External Depth: 2.5mm
• External Length / Height: 6mm
• External Width: 3.2mm
• Height: 6mm
• No. of Pins: 2Pins
• Operating Temperature Range: -55°C to +105°C
• Tantalum Capacitor Case: 2312 [6032 Metric]
• Tolerance +: 20%
• Tolerance -: 20%
• Voltage Rating V DC: 2.5V
