Documents et téléchargements
Description
VISHAY - MAL215097815E3 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 220 µF, 63 V, 5000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 220µF
- Voltage Rating: 63V
- ESR: -
- Product Range: 150 CRZ Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 637mA
- Diameter: 12.5mm
- Height: 16mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (27-Jun-2018)
