VISHAY - MPMA50011002AT5 - Resistor Network, 5 kohm, MPMA, 10 kohm, 2 Elements, Voltage Divider, SOT-23
- Resistance R1: 5kohm
- Product Range: MPMA Series
- Resistance R2: 10kohm
- No. of Elements: 2Elements
- Network Circuit Type: Voltage Divider
- Resistor Case Style: SOT-23
- No. of Pins: 3Pins
- Power Rating per Element: 100mW
- Absolute Resistance Tolerance: 0.10%
- Absolute TCR: ± 25ppm/°C
- Automotive Qualification Standard: -
- Power Rating: 200mW
- Resistance: 10kohm
- Resistance Tolerance: ± 0.1%
- Temperature Coefficient: ± 25ppm/°C
- Voltage Rating: 100V
