KEMET - T520D108M2R5ATE015 - Tantalum Polymer Capacitor, KO-CAP®, 1000 µF, ± 20%, 2.5 V, D, 0.015 ohm, 2917 [7343 Metric]
- Capacitance: 1000µF
- Voltage Rating: 2.5V
- Product Range: T52X KO-CAP®
- Capacitance Tolerance: ± 20%
- Manufacturer Size Code: D
- ESR: 0.015ohm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: 2917 [7343 Metric]
- Capacitor Mounting: SMD
- Capacitor Terminals: SMD
- ESR Frequency: 102kHz
- ESR Temperature: 25°C
- External Depth: 2.8mm
- External Length / Height: 7.3mm
- External Width: 4.3mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +105°C
- Reel Quantity: 500
- Tantalum Capacitor Case: 2917 [7343 Metric]
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 2.5V
