KEMET - T520D687M004ATE012 - Tantalum Polymer Capacitor, KO-CAP®, 680 µF, ± 20%, 4 V, D, 0.012 ohm, 2917 [7343 Metric]
- Capacitance: 680µF
- Voltage Rating: 4V
- Product Range: T52X KO-CAP®
- Capacitance Tolerance: ± 20%
- Manufacturer Size Code: D
- ESR: 0.012ohm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: 2917 [7343 Metric]
- Capacitor Mounting: SMD
- Capacitor Terminals: SMD
- ESR Frequency: 101kHz
- ESR Temperature: 25°C
- External Depth: 2.8mm
- External Length / Height: 7.3mm
- External Width: 4.3mm
- Height: 7.3mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +105°C
- Reel Quantity: 500
- Tantalum Capacitor Case: 2917 [7343 Metric]
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 4V
