Description
BROADCOM - HLMP-EG08-Y2000 - LED, Red, Through Hole, T-1 3/4 (5mm), 20 mA, 1.9 V, 626 nm
- LED Colour: Red
- LED Mounting: Through Hole
- LED Case Size: T-1 3/4 (5mm)
- Forward Current If: 20mA
- Forward Voltage: 1.9V
- Wavelength Typ: 626nm
- Luminous Intensity: 27cd
- Viewing Angle: 8°
- Lens Shape: Round
- Product Range: -
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (27-Jun-2018)
- Bulb Size: T-1 3/4 (5mm)
- Luminous Intensity @ If Max: 12000mcd
- Luminous Intensity @ If Min: 9300mcd
