Description
VISHAY - MAL218097203E3 - Polymer Aluminium Electrolytic Capacitor, 560 µF, 20 V, Radial Can - SMD, 2500 hours @ 105°C
- Capacitance: 560µF
- Voltage Rating: 20V
- AE Capacitor Case: Radial Can - SMD
- Product Range: 180 CPS Series
- ESR: -
- Lifetime @ Temperature: 2500 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Capacitance Tolerance: ± 20%
- Capacitor Case Style: Radial Can - SMD
- Capacitor Terminals: SMD
- Diameter: 10mm
- External Depth: 10.4mm
- External Width: 10.4mm
- Height: 12.6mm
- Leakage Current: 2.24mA
- Ripple Current AC: 5.6A
