Description
VISHAY - MKP1848S53070JK2A - Power Film Capacitor, Metallized PP, Radial Box - 2 Pin, 3 µF, ± 5%, DC Link, Through Hole
- Capacitance: 3µF
- Voltage Rating: 700V
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 5%
- Product Range: MKP1848S Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 27.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 5%
- ESR: 0.0225ohm
- Voltage Rating V DC: 700V
