Description
VISHAY - MPT42002AT1 - Resistor Network, 10 kohm, MPT, 10 kohm, 2 Elements, Voltage Divider, SC-70
- Resistance: 10kohm
- Product Range: MPT Series
- No. of Elements: 2Elements
- Network Circuit Type: Isolated
- Resistor Case Style: SC-70
- No. of Pins: 4Pins
- Voltage Rating: 50V
- Power Rating per Element: 75mW
- Resistance Tolerance: ± 0.1%
- Temperature Coefficient: ± 25ppm/°C
- Automotive Qualification Standard: -
- RoHS Phthalates Compliant: Yes
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +125°C
- Power Rating: 150mW
- Ratio: 1
- Ratio Tolerance: 0.05%
- Resistance R1: 10kohm
- Resistance R2: 10kohm
- Resistances R1 / R2: 10K/10K
- Resistor Element Material: Thin Film
- Resistor Mounting: Surface Mount Device
