Description
AMPHENOL INDUSTRIAL - MS3120F12-10SX - Circular Connector, MIL-DTL-26482 Series I, Wall Mount Receptacle, 10 Contacts, Crimp Socket
- Military Specification: MIL-DTL-26482 Series I
- Circular Connector Shell Style: Wall Mount Receptacle
- No. of Contacts: 10Contacts
- Circular Contact Type: Crimp Socket
- Coupling Style: Bayonet
- Insert Arrangement: 12-10
- Connector Body Material: Aluminium Alloy Body
- Connector Body Plating: Olive Drab Chromate over Cadmium
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Insert Rotation: X
- Service Class: Environmentally Sealed
- Product Range: MIL-DTL-26482 Series I
