Omschrijving
JST (JAPAN SOLDERLESS TERMINALS) - 04SUR04SUR32W150 - Cable Assembly, 4 Ways, 0.8 mm, 150 mm, 6 "
- Connector to Connector: IDC Receptacle to IDC Receptacle
- No. of Positions: 4Ways
- Cable Length - Imperial: 6"
- Cable Length - Metric: 150mm
- Connector Pitch: 0.8mm
- Cable Pitch: -
- Product Range: -
- SVHC: No SVHC (17-Dec-2015)
- Body Plating: Tin
- Cable Assembly Type: Picoflex, Ribbon
- Cable Length: 150mm
- Connector Type A: IDC Socket
- Connector Type B: IDC Socket
- Current Rating: 500mA
- Flammability Rating: UL94V-0
- Lead Length: 150mm
- Lead Spacing: 0.8mm
- Material: Polyamide
- No. of Cores: 4Core
- Operating Temperature Max: 85°C
- Operating Temperature Min: -25°C
- Operating Temperature Range: -25°C to +85°C
- Pitch Spacing: 0.8mm
- Working Voltage: 30V
