Omschrijving
HARTING - 09 69 210 0033 - Combination Layout D Sub Connector, Mixed Signal, D Sub-M, DA-3W3, Plug, 3 Contacts, Solder
- Product Range: D Sub-M Series
- Insert Arrangement: DA-3W3
- No. of Signal Contacts: 0Contacts
- Gender: Plug
- No. of Power Positions: 3
- Contact Termination Type: Solder
- D Sub Shell Size: DA
- Connector Body Material: Steel Body
- Contact Material: Copper Alloy
- Contact Plating: Gold Plated Contacts
- SVHC: No SVHC (15-Jan-2018)
- Approval Category: DIN 41652, part 1
- Body Plating: Tin
- Contact Termination: Solder
- Current Rating: 5A
- Flammability Rating: UL94V-0
- Material: Steel
- No. of Contacts: 3Contacts
- No. of Mating Cycles: 500
- Operating Temperature Max: 125°C
- Operating Temperature Min: 55°C
- Working Voltage: 750V
