1-1337463-0 RF Coaxial, BNC, Straight Plug, 50ohm GREENPAR - Te Connectivity

GREENPAR - TE CONNECTIVITYSKU:1-1337463-0 Bestelcode:1170188

Prijs:
Actie prijs€10,59

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (22 units)

Documenten en downloads

Omschrijving

GREENPAR - TE CONNECTIVITY - 1-1337463-0 - RF / Coaxial Connector, BNC Coaxial, Straight Plug, 50 ohm, Brass

  • Connector Type: BNC Coaxial
  • Connector Body Style: Straight Plug
  • Coaxial Termination: -
  • Impedance: 50ohm
  • Coaxial Cable Types: -
  • Contact Material: Brass
  • Contact Plating: Silver Plated Contacts
  • Frequency Max: 1GHz
  • Connector Mounting: Cable Mount
  • Product Range: -
  • SVHC: No SVHC (12-Jan-2017)
  • Body Plating: Silver
  • Centre Contact Resistance: 1.5mohm
  • Coaxial Type: RG58
  • Connector Mounting Orientation: Cable
  • Dielectric Material: PTFE
  • Insulation Resistance: 5000Mohm
  • Material: Brass
  • No. of Mating Cycles: 500
  • Operating Frequency Max: 1GHz
  • Operating Temperature Max: 165°C
  • Operating Temperature Min: -65°C
  • Outer Contact Resistance: 1mohm
  • Peak Voltage AC: 500V
  • Withstand Voltage: 1500V
  • Working Voltage: 500V
