AMP - TE CONNECTIVITY - 1-794108-0 - Pin Header, Right Angle, Wire-to-Board, 4.14 mm, 2 Rows, 24 Contacts, Through Hole Right Angle
- Pitch Spacing: 4.14mm
- No. of Contacts: 24Contacts
- Gender: Plug
- Product Range: Mini Universal MATE-N-LOK Series
- Contact Termination Type: Through Hole
- No. of Rows: 2Rows
- Contact Plating: Tin Plated Contacts
- Contact Material: Brass
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: CSA, UL, VDE
- Colour: White
- Current per Contact Max: 10.5A
- Flammability Rating: UL94V-0
- Insulation Resistance: 100Mohm
- Operating Temperature Max: 65°C
- Operating Temperature Min: 20°C
- Test Voltage: 1500V
