10236-55G3PL Receptacle, MDR, R/A, 36WAY 3M

3M - 10236-55G3PL - D Sub Connector, Right Angle, Mini D (Ribbon Connector), Receptacle, 102, 36 Contacts, Solder

• D Sub Connector Type: Mini D (Ribbon Connector)
• Gender: Receptacle
• Product Range: 102 Series
• No. of Contacts: 36Contacts
• Contact Termination Type: Solder
• Connector Mounting: Through Hole Mount Right Angle
• Contact Material: Copper Alloy
• Contact Plating: Gold Plated Contacts
• Connector Body Material: Steel Body
• SVHC: No SVHC (15-Jan-2019)
• Colour: Beige
• Connector Mounting Orientation: PC Board
• Connector Type: Micro D Ribbon
• Contact Termination: Through Hole Right Angle
• Current Rating: 1A
• Flammability Rating: UL94V-0
• Insulation Resistance: 500Mohm
• Material: Steel
• Operating Temperature Max: 105°C
• Operating Temperature Min: -55°C
• Pitch Spacing: 1.27mm
• Termination Method: Solder
• Withstand Voltage: 500V
