Omschrijving
SCHURTER - 1241.2801 - Vandal Resistant Switch, MCS, 19 mm, SPST-NO, Off-(On), Flush, Natural
- Contact Configuration: SPST-NO
- Actuator / Cap Colour: Natural
- Product Range: MCS Series
- Switch Operation: Off-(On)
- Illumination Colour: Non-illuminated
- Switch Terminals: Solder Lug
- Contact Current Max: 125mA
- Contact Voltage AC Max: -
- Operating Force: 3.7N
- Contact Voltage DC Max: 48V
- SVHC: No SVHC (27-Jun-2018)
- Behind Panel Depth: 8.8mm
- Bezel Diameter: 21.5mm
- Contact Current DC Max: 125mA
- Contact Voltage DC Min: 4VDC
- Contact Voltage VDC: 48V
- External Width: 21.5mm
- Height Above Panel: 1mm
- IP / NEMA Rating: IP40
- IP Rating: IP65
- Insulation Resistance: 100Mohm
- No. of Electrical Operations: 1000000
- Operating Temperature Max: 60°C
- Operating Temperature Min: -25°C
- Panel Cutout Diameter: 19mm
- Panel Thickness Min: 1mm
- Pushbutton Actuator Style: Flush
- Pushbutton Switch Type: Anti-Vandal
- Stroke Length Max: 0.4mm
- Switch Mounting: Panel
