STORM INTERFACE - 1K042101 - Keypad, STORM 1000, 1 x 4, Matrix, Chromed Zinc, 50 mA, 24 V
- Product Range: STORM 1000 Series
- Keypad Array: 1 x 4
- Keypad Output: Matrix
- Housing Material: Chromed Zinc
- Contact Current Max: 50mA
- Contact Voltage DC Nom: 24V
- No. of Keys: 4
- Panel Cutout Width: 42.5mm
- Panel Cutout Height: 118.5mm
- SVHC: No SVHC (27-Jun-2018)
- Breakdown Voltage Vbr: 500V
- Colour: Silver
- Contact Current DC Max: 50mA
- Contact Current Rating: 50mA
- Contact Resistance: 100mohm
- Contact Voltage DC Max: 24V
- Height: 118.5mm
- IP / NEMA Rating: IP67
- Insulation Resistance: 50Mohm
- Material: Chromed Zinc
- No. of Mechanical Operations: 4000000
- Operating Force: 1.8N
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Time: 5ms
