Omschrijving
AMP - TE CONNECTIVITY - 2-5499206-8 - Pin Header, Straight, Wire-to-Board, 2.54 mm, 2 Rows, 34 Contacts, Through Hole Straight, AMP-LATCH
- Pitch Spacing: 2.54mm
- No. of Contacts: 34Contacts
- Gender: Header
- Product Range: AMP-LATCH Series
- Contact Termination Type: Through Hole
- No. of Rows: 2Rows
- Contact Plating: Gold Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA, UL
- Colour: Blue
- Current Rating: 1A
- Flammability Rating: UL94V-0
- Insulation Resistance: 1Gohm
- Material: Glass Reinforced Thermoplastic
- No. of Mating Cycles: 200
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Polarisation Type: Bump/Clip
- Terminal Plating: Tin/lead over nickel
- Withstand Voltage: 500V
