Omschrijving
ALPHA WIRE - 2855/1 WH005 - Wire, Solid, Hook Up, PTFE, White, 22 AWG, 0.324 mm², 100 ft, 30.5 m
- Jacket Material: PTFE
- Jacket Colour: White
- Wire Gauge: 22AWG
- Conductor Area CSA: 0.324mm²
- Reel Length (Imperial): 100ft
- Reel Length (Metric): 30.5m
- No. of Max Strands x Strand Size: Solid
- Voltage Rating: 600V
- Conductor Material: Copper
- External Diameter: 1.143mm
- Approval Specification: MIL-DTL-16878/4 (Type E), UL 1213
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Conductor Make-up: 1 / 22AWG
- Outer Diameter: 1.14mm
- Wire Size: 22AWG
