2N4401 Transistor, NPN, 40V, 0.6a, TO-92 multicomp Pro

MULTICOMP PROSKU:2N4401 Bestelcode:1574373

Prijs:
Actie prijs€0,29

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (44653 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - 2N4401 - Bipolar (BJT) Single Transistor, NPN, 40 V, 600 mA, 625 mW, TO-92, Through Hole

  • Transistor Polarity: NPN
  • Collector Emitter Voltage V(br)ceo: 40V
  • Transition Frequency ft: 250MHz
  • Power Dissipation Pd: 625mW
  • DC Collector Current: 600mA
  • DC Current Gain hFE: 100hFE
  • Transistor Case Style: TO-92
  • No. of Pins: 3Pins
  • Operating Temperature Max: 150°C
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: MSL 1 - Unlimited
  • SVHC: No SVHC (15-Jan-2019)
  • Collector Emitter Saturation Voltage Vce(on): 400mV
  • Current Ic @ Vce Sat: 150mA
  • Current Ic Fall Time Measurement: 150mA
  • Current Ic hFE: 1mA
  • Fall Time @ Ic: 255ns
  • Full Power Rating Temperature: 25°C
  • Gain Bandwidth ft Typ: 250MHz
  • Hfe Min: 40
  • No. of Transistors: 1
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +150°C
  • Pin Configuration: b
  • Termination Type: Through Hole
  • Voltage Vcbo: 60V
