Omschrijving
SCHURTER - 3404.2417.11 - Fuse, Surface Mount with Clip/Holder, 1.25 A, Slow Blow, 250 VAC, 125 VDC, 11.1mm x 4.2mm
- Fuse Current: 1.25A
- Product Range: UMZ 250 Series
- Voltage Rating VAC: 250VAC
- Voltage Rating V DC: 125VDC
- Blow Characteristic: Time Delay
- Fuse Case Style: Fuse With Holder
- Breaking Capacity Current AC: 35A
- Breaking Capacity Current DC: 100A
- SVHC: Lead (15-Jan-2019)
- Breaking Capacity: 200A @ 277V AC, 100A @ 125V DC, 35A @ 250V DC, 200A @ 63V AC / DC
- External Depth: 3.8mm
- External Height: 3.9mm
- External Width: 11.1mm
- Fuse Size Held: 11.1mm x 3.8mm
- Fuse Type Blowing Characteristic: Time Delay
- SMD Fuse Case Style: SMD
