Omschrijving
AMP - TE CONNECTIVITY - 350431-1 - Pin Header, Vertical, Wire-to-Board, 6.35 mm, 2 Rows, 6 Contacts, Through Hole Straight
- Pitch Spacing: 6.35mm
- No. of Contacts: 6Contacts
- Gender: Header
- Product Range: Universal MATE-N-LOK Series
- Contact Termination Type: Through Hole
- No. of Rows: 2Rows
- Contact Plating: Tin Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CSA, UL
- Colour: Natural
- Current Rating: 12A
- Flammability Rating: UL94V-2
- Material: Nylon - GF
- Operating Temperature Max: 105°C
- Operating Temperature Min: -55°C
- Voltage Rating VAC: 600V
