Omschrijving
MYRRA - 45024 - PCB Transformer, UI 30 x 7.5, Encapsulated Safety Isolating, 115V, 230V, 2 x 24V, 4 VA, 50Hz / 60Hz
- Power Rating: 4VA
- Secondary Voltages: 2 x 24V
- Current Rating: 83mA
- Isolation Transformer Primary Voltages: 1 x 115V, 1 x 230V
- Plug Type: -
- Product Range: 45000 Series
- SVHC: No SVHC (27-Jun-2018)
- AC Power: 4VA
- External Depth: 44mm
- External Length / Height: 19mm
- External Width: 53mm
- Input Voltage: 230V
- Output Voltage: 24V
- Primary Voltages: 115V to 230V
- Secondary Current Nom: 83mA
- Secondary Power: 2VA
- Transformer Type: Encapsulated
