TE CONNECTIVITY - 5-1393302-1 - Automotive Relay, 24 VDC, 40 A, SPDT, Through Hole, Solder, Power Relay F4
- Coil Voltage: 24VDC
- Contact Current: 40A
- Contact Configuration: SPDT
- Relay Mounting: Through Hole
- Relay Terminals: Solder
- Product Range: Power Relay F4 Series
- Contact Voltage DC Nom: 24V
- Coil Resistance: 268ohm
- Contact Material: Silver
- SVHC: No SVHC (07-Jul-2017)
- Coil Type: DC Monostable
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 20A
- External Depth: 25.9mm
- External Height: 24.9mm
- External Width: 25.9mm
- Nom Operating Power: 2.1W
- Relay Type: Power
