524-532-21 LED Indicator, 12VDC, Green Marl

MARLSKU:524-532-21 Bestelcode:9737901

Prijs:
Actie prijs€33,54

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5 units)

Documenten en downloads

Omschrijving

MARL - 524-532-21 - LED Panel Mount Indicator, Weatherproof, Green, 12 VDC, 8.1 mm, 20 mA, 23 cd, IP67

  • LED Colour: Green
  • Operating Voltage: 12VDC
  • Mounting Hole Dia: 8.1mm
  • Forward Current If: 20mA
  • Luminous Intensity: 23cd
  • IP / NEMA Rating: IP67
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Bezel Diameter: 12.7mm
  • Bulb Size: 7mm
  • Current If Luminous Intensity: 20mA
  • External Diameter: 12.7mm
  • External Length / Height: 36mm
  • Fixing Hole Diameter: 8.1mm
  • Forward Current If Max: 20mA
  • Forward Voltage: 12V
  • Forward Voltage VF Max: 12V
  • LED / Lamp Size: 7mm
  • Length Behind Bezel: 34mm
  • Luminous Intensity Typ: 6000mcd
  • Material: Stainless Steel
  • Operating Temperature Max: 95°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Range: -40°C to +95°C
  • Peak Wavelength: 525nm
  • Voltage Rating V DC: 12V
  • Voltage Vf Typ: 12VDC
  • Wavelength Typ: 525nm
