62GB-12E12-10PN Circular Conn, Receptacle, 12-10, Panel Amphenol Ltd

AMPHENOL LTDSKU:62GB-12E12-10PN Bestelcode:3911299

Prijs:
Actie prijs€42,61

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (33 units)

Documenten en downloads

Omschrijving

AMPHENOL LTD - 62GB-12E12-10PN - Circular Connector, 62GB, Box Mount Receptacle, 10 Contacts, Solder Pin, Bayonet, 12-10

  • Product Range: 62GB Series
  • Circular Connector Shell Style: Box Mount Receptacle
  • No. of Contacts: 10Contacts
  • Circular Contact Type: Solder Pin
  • Coupling Style: Bayonet
  • Insert Arrangement: 12-10
  • Connector Body Material: Aluminium Alloy Body
  • Connector Body Plating: Olive Drab Zinc
  • Contact Material: Copper Alloy
  • Contact Plating: Gold
  • Insert Rotation: N
  • Service Class: Environmentally Sealed
  • Equivalent Military Specification: MIL-DTL-26482 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Category: MIL-C-26482
  • Current Rating: 7.5A
  • IP / NEMA Rating: IP67
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Voltage Rating VAC: 700V
  • Working Voltage: 700VDC
