AVB2.3/2/18 TRANSFORMER, 2.3VA, 2 X 18V BLOCK

BLOCKSKU:AVB2.3/2/18 Bestelcode:1131478

Prijs:
Actie prijs€19,26

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (6 units)

Documenten en downloads

Omschrijving

BLOCK - AVB2.3/2/18 - PCB Transformer, Class II, Encapsulated Safety Isolating, 2 x 115V, 2 x 18V, 2.3 VA, 50Hz / 60Hz

  • Power Rating: 2.3VA
  • Secondary Voltages: 2 x 18V
  • Current Rating: 63mA
  • Isolation Transformer Primary Voltages: 2 x 115V
  • Plug Type: -
  • Product Range: -
  • SVHC: No SVHC (12-Jan-2017)
  • AC Power: 2.3VA
  • Approval Bodies: CSA, UL, VDE
  • External Depth: 29mm
  • External Length / Height: 27.3mm
  • External Width: 32.3mm
  • Flammability Rating: UL94V-0
  • Hole Spacing - Length: 20mm
  • Input Voltage: 230V
  • Isolation Voltage: 5kV
  • Lead Spacing: 5mm
  • Output 2 Voltage Max: 18V
  • Output Voltage: 18V
  • Pin Diameter: 0.8mm
  • Pin Length: 5mm
  • Pitch Spacing: 5mm
  • Primary Voltages: 2 x 115V
  • Regulation: 59%
  • Secondary Current Nom: 63mA
  • Secondary Power: 1.15VA
  • Supply Voltage V AC: 230V
  • Transformer Type: Isolation
  • Weight: 110g
