BLOCK - AVB3.2/2/24 - PCB Transformer, Class II, Encapsulated Safety Isolating, 2 x 115V, 2 x 24V, 3.2 VA, 50Hz / 60Hz
- Power Rating: 3.2VA
- Secondary Voltages: 2 x 24V
- Current Rating: 7mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 3.2VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 15mm
- External Length / Height: 22mm
- External Width: 22.7mm
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 15mm
- Input Voltage: 230V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Output 2 Voltage Max: 24V
- Output Voltage: 24V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 5mm
- Primary Voltages: 2 x 115V
- Regulation: 30%
- Secondary Current Nom: 66mA
- Secondary Power: 1.6VA
- Supply Voltage V AC: 230V
- Transformer Type: Isolation
- Weight: 24g
