EPCOS - B32332I6606J082 - Motor Run Capacitor, Metallized PP, Can, 60 µF, ± 5%, Stud Mount - M8, 450 V
- Capacitance: 60µF
- Product Range: B32332 Series
- Voltage Rating: 450VAC
- Capacitor Terminals: Quick Connect, Snap-In
- Capacitance Tolerance: ± 5%
- dv/dt Rating: 10V/µs
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitor Case Style: Can
- Height: 103mm
- Diameter: 45mm
- Stud Size - Metric: M8
- Operating Temperature Min: -25°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Capacitance Tolerance ±: ± 5%
- Operating Temperature Range: -25°C to +85°C
- Voltage Rating VAC: 450V
