B4B-Zr(LF)(Sn) Header, Top Entry, 4WAY JST (Japan Solderless Terminals)

JST (JAPAN SOLDERLESS TERMINALS)SKU:B4B-ZR(LF)(SN) Bestelcode:9491791

Prijs:
Actie prijs€0,28

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (51386 units)

Documenten en downloads

Omschrijving

JST (JAPAN SOLDERLESS TERMINALS) - B4B-ZR(LF)(SN) - Pin Header, Top Entry, Wire-to-Board, 1.5 mm, 1 Rows, 4 Contacts, Through Hole, ZH

  • Pitch Spacing: 1.5mm
  • No. of Contacts: 4Contacts
  • Gender: Header
  • Product Range: ZH Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 1Rows
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Brass
  • SVHC: No SVHC (27-Jun-2018)
  • Approval Bodies: CSA, UL
  • Colour: Natural White
  • Contact Resistance: 20mohm
  • Current Rating: 1A
  • External Length / Height: 5.6mm
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 500Mohm
  • Material: Nylon
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -25°C
  • Voltage Rating V DC: 50V
  • Voltage Rating VAC: 50V
  • Withstand Voltage: 500V
