B72650M0271K072 Varistor, 3225, 8.6J, 275VAC EPCOS

EPCOSSKU:B72650M0271K072 Bestelcode:9958533

Prijs:
Actie prijs€1,29

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1506 units)

Documenten en downloads

Omschrijving

EPCOS - B72650M0271K072 - TVS Varistor, 275 V, 350 V, B726, 710 V, 3225 [8063 Metric], Metal Oxide Varistor (MOV)

  • Voltage Rating VAC: 275V
  • Voltage Rating V DC: 350V
  • Product Range: B726 Series
  • Clamping Voltage Vc Max: 710V
  • Varistor Case Style: 3225
  • Varistor Type: Metal Oxide Varistor (MOV)
  • Peak Surge Current @ 8/20µs: 400A
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Peak Energy (10/1000uS): 8.6J
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (27-Jun-2018)
  • Capacitance: 50pF
  • Clamping Voltage @ 8/20µs Max: 710V
  • Operating Temperature Range: -40°C to +85°C
  • Peak Pulse Current IPP @ 8/20µs: 400A
  • Suppressor Type: Varistor
  • Surge Current: 400A
  • Transient Energy: 8.6J
  • Varistor Voltage: 430V
  • Varistor Voltage @ 1mA: 387V
  • Varistor Voltage @ 1mA Max: 473V
  • Varistor Voltage Tolerance +: 10%
  • Varistor Voltage Tolerance -: 10%
