HIRSCHMANN - CM02E20-27P - Circular Connector, Panel Mount Plug, 14 Contacts, Screw Pin, Nylon (Polyamide) Body
- Product Range: -
- Circular Connector Shell Style: Panel Mount Plug
- No. of Contacts: 14Contacts
- Circular Contact Type: Screw Pin
- Coupling Style: -
- Connector Body Material: Nylon (Polyamide) Body
- Connector Body Plating: -
- Contact Material: Copper Alloy
- Contact Plating: Silver
- SVHC: Lead (27-Jun-2018)
- Cable Diameter Max: 14mm
- Cable Diameter Min: 12mm
- Colour: Black
- Connector Mounting: Panel Mount
- Connector Shell Size: 20-27
- Connector Type: Circular Industrial
- Contact Gender: Pin
- Contact Plating: Silver Plated Contacts
- Contact Resistance: 4mohm
- Contact Termination: Screw
- Contact Termination Type: Screw
- Current Rating: 5A
- Flammability Rating: UL94V-1
- Gender: Plug
- IP / NEMA Rating: IP67
- Insert Arrangement: 20-27
- Operating Temperature Max: 90°C
- Operating Temperature Min: -40°C
- PCB Hole Diameter: 3.2mm
- Panel Cutout Diameter: 29.5mm
- Thread Size: PG16
- Voltage Rating V DC: 50V
- Voltage Rating VAC: 50V
- Wire Area Size Max: 1.5mm²
- Wire Size: 16AWG
- Working Voltage: 50V
