CMX60D10 SSR, 10A, 60VDC SENSATA/CRYDOM

SENSATA/CRYDOMSKU:CMX60D10 Bestelcode:1200211

Prijs:
Actie prijs€68,18

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (894 units)

Documenten en downloads

Omschrijving

SENSATA/CRYDOM - CMX60D10 - Solid State Relay, CMX Series, DIP, DC Output, SPST-NO, 10 A, 60 VDC, PCB, Through Hole, DC Switch

  • Contact Configuration: SPST-NO
  • Load Current: 10A
  • Operating Voltage Max: 60VDC
  • Relay Mounting: PCB
  • Relay Terminals: Through Hole
  • Switching Mode: DC Switch
  • Operating Voltage Min: 0VDC
  • Control Voltage Min: 3VDC
  • Control Voltage Max: 10VDC
  • Product Range: CMX Series
  • SVHC: No SVHC (07-Jul-2017)
  • Control Current @ 5VDC: 15mA
  • Control Voltage DC Max: 10VDC
  • Control Voltage DC Min: 3VDC
  • Control Voltage Range: 3V DC to 10V DC
  • Control Voltage Type: DC
  • External Depth: 7.6mm
  • External Length / Height: 25.4mm
  • External Width: 43mm
  • Forward Current If: 15mA
  • Input Current: 15mA
  • Input Impedance: 300ohm
  • Input Voltage: 3V DC to 10V DC
  • Insulation Resistance: 1000Mohm
  • Isolation Voltage: 2.5kV
  • Leakage Current: 0.1mA
  • Load Current Max: 10A
  • Load Current Min: 0A
  • Load Current RMS Max: 10A
  • Load Voltage DC Max: 60V
  • Load Voltage DC Min: 0V
  • Load Voltage Max: 60VDC
  • Load Voltage Range: 0V DC to 60V DC
  • No. of Pins: 4Pins
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -30°C
  • Output Type: MOSFET
