CTB9400/3 Terminal Block, Pluggable, 3Pos, 12AWG Camdenboss

CAMDENBOSS - CTB9400/3 - Pluggable Terminal Block, 7.5 mm, 3 Ways, 30AWG to 12AWG, 2.5 mm², Screw, 12 A

• Pitch Spacing: 7.5mm
• No. of Positions: 3Ways
• Wire Size (AWG): 30AWG to 12AWG
• Conductor Area CSA: 2.5mm²
• Wire Connection Method: Screw
• Rated Current: 12A
• Rated Voltage: 500V
• Product Range: CTB9400 Series
• SVHC: No SVHC (15-Jan-2019)
• Colour: Green
• Connector Mounting: Cable Mount
• Connector Type: Terminal Block, Pluggable
• Contact Material: Brass
• Contact Plating: Copper Plated Contacts
• Current Rating: 12.0A
• Flammability Rating: UL94V-0
• No. of Contacts: 3Contacts
• Operating Temperature Max: 125°C
• Operating Temperature Min: -20°C
• Screw Material: Steel
• Screw Plating: Zinc
• Thread Size: M3
• Voltage Rating AC Max: 750V
• Voltage Rating VAC: 750V
• Wire Area Size Max: 2.5mm²
• Wire Size AWG Max: 12AWG
• Wire Size AWG Min: 30AWG
