CUB7TCS0 Electronic Timer, Contact, Lcd Red Lion Controls

RED LION CONTROLS - CUB7TCS0 - Panel Mount Timer, Low Voltage, 9 VDC, 28 VDC, 0.001 s, 1 h, 22.2 mm, 45 mm

• Supply Voltage Min: 9VDC
• Supply Voltage Max: 28VDC
• Time Min: 0.001s
• Time Max: 1h
• Panel Cutout Height: 22.2mm
• Panel Cutout Width: 45mm
• Product Range: -
• SVHC: No SVHC (12-Jan-2017)
• Digit Height: 8.9mm
• External Depth: 40mm
• External Length / Height: 28mm
• External Width: 51mm
• Operating Temperature Max: 50°C
• Operating Temperature Min: 0°C
• Operating Temperature Range: 0°C to +50°C
• Reset Time: 15ms
• Supply Voltage AC Max: 300V
• Supply Voltage AC Min: 10V
• Supply Voltage DC Max: 300V
• Supply Voltage DC Min: 10V
• Supply Voltage Range: 9V DC to 28V DC
• Time Range: 0.001sec to 1hr
