D2F-L3 Microswitch, SPDT Omron

OMRONSKU:D2F-L3 Bestelcode:1448153

Prijs:
Actie prijs€4,76

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1693 units)

Documenten en downloads

Omschrijving

OMRON - D2F-L3 - Microswitch, Snap Action, Simulated Roller Lever, SPDT, Solder, 3 A, 30 VDC

  • Microswitch Type: Snap Action
  • Microswitch Actuator: Simulated Roller Lever
  • Contact Configuration: SPDT
  • Switch Terminals: Solder
  • Contact Current Max: 3A
  • Contact Voltage DC Nom: 30VDC
  • Product Range: D2F Series
  • Contact Voltage AC Nom: 125VAC
  • Operating Force Max: 80gf
  • Actuation Type: Simulated Roller Lever
  • Actuator Type: Simulated Roller Lever
  • Approval Bodies: CSA
  • Approval Category: UL Recognised
  • Contact Current @ Contact Voltage AC Max: 3A
  • Contact Current @ Contact Voltage DC Max: 2A
  • Contact Current AC Max: 3A
  • Contact Current DC Max: 2A
  • Contact Resistance: 30mohm
  • Contact Voltage AC Max: 125VAC
  • Contact Voltage DC Max: 30VDC
  • Dielectric Strength VDC: 600VAC
  • Differential Travel Max: 0.5mm
  • External Depth: 5.8mm
  • External Length / Height: 6mm
  • External Width: 12.8mm
  • Fixing Centres: 6.5mm
  • Insulation Resistance: 100Mohm
  • Insulation Resistance Voltage: 500VDC
  • Lead Length: 3.5mm
  • Lead Spacing: 5.08mm
  • Lever Length: 10mm
  • No. of Electrical Operations: 30000
  • Operating Temperature Max: 65°C
