DB1C-A1AA Microswitch, SPDT, Plunger Actuator ZF Electronics

ZF ELECTRONICSSKU:DB1C-A1AA Bestelcode:1518979

Prijs:
Actie prijs€5,77

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (2806 units)

Documenten en downloads

Omschrijving

ZF ELECTRONICS - DB1C-A1AA - Microswitch, Subminiature, Plunger, SPDT, Solder, 6 A

  • Microswitch Type: Snap Action
  • Microswitch Actuator: Plunger
  • Contact Configuration: SPDT
  • Switch Terminals: Solder
  • Contact Current Max: 5A
  • Contact Voltage DC Nom: -
  • Product Range: DP Series
  • Contact Voltage AC Nom: 250VAC
  • Operating Force Max: 150gf
  • SVHC: No SVHC (15-Jan-2019)
  • Actuation Type: Plunger
  • Actuator Type: Plunger
  • Approval Bodies: ENEC, KEMA-KEUR
  • Approval Category: UL Recognised
  • Contact Current AC: 5A
  • Contact Current AC Max: 5A
  • Contact Voltage AC Max: 250V
  • Differential Travel Max: 0.1mm
  • External Depth: 6.5mm
  • External Length / Height: 9mm
  • External Width: 20mm
  • Fixing Centres LxW: 9.5mm
  • Flammability Rating: UL 94V- O
  • IP / NEMA Rating: IP50
  • Material: PET
  • No. of Electrical Operations: 6000
  • Operating Temperature Max: 120°C
  • Operating Temperature Min: -40°C
  • Over Travel Min: 0.6mm
  • Pre-travel: 1mm
  • Switch Case: PET (Polyethylene Terephthalate)
