Omschrijving
COILCRAFT - DO1608C-223MLC - Power Inductor (SMD), 22 µH, 950 mA, Unshielded, 700 mA, DO1608C
- Inductance: 22µH
- RMS Current (Irms): 950mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): 700mA
- Product Range: DO1608C Series
- Power Inductor Case: 6.6mm x 4.45mm x 2.92mm
- DC Resistance Max: 0.37ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Self Resonant Frequency Min: 20MHz
