Omschrijving
PANASONIC - EEE0JA220SR - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 22 µF, 6.3 V, 2000 hours @ 85°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 22µF
- Voltage Rating: 6.3V
- ESR: -
- Product Range: S Series
- Lifetime @ Temperature: 2000 hours @ 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Ripple Current AC: 29mA
- Diameter: 4mm
- Height: 5.4mm
- Automotive Qualification Standard: AEC-Q200
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (15-Jan-2019)
