PANASONIC - EEUFR0J331B - Electrolytic Capacitor, 330 µF, 6.3 V, ± 20%, Radial Leaded, 5000 hours @ 105°C, Polar
- Capacitance: 330µF
- Voltage Rating: 6.3V
- Product Range: FR Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 6.3mm
- Lead Spacing: 2.5mm
- Height: 11.2mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 5000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 11.2mm
- Impedance: 0.13ohm
- Lead Diameter: 0.5mm
- Operating Temperature Range: -40°C to +105°C
- Ripple Current AC: 455mA
