Omschrijving
PANASONIC - ETQP5M100YFC - Power Inductor (SMD), Choke Coil, 10 µH, 7.1 A, Shielded, 10.7 A, PCC-M1054M Series
- Inductance: 10µH
- RMS Current (Irms): 7.1A
- Inductor Construction: Wirewound
- Saturation Current (Isat): 10.7A
- Product Range: PCC-M1054M Series
- Power Inductor Case: 10.7mm x 10mm x 5.4mm
- DC Resistance Max: 0.0262ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (07-Jul-2017)
- Automotive Qualification Standard: AEC-Q200
- External Depth: 5.4mm
- External Length / Height: 10mm
- External Width: 10.7mm
- Height: 10mm
